///Quark-1200, Quark Series 1200 W Full Modular Power Supply with LED Indicator, 80Plus Platinum Certified, Single +12V Rail, Intel 4th Gen CPU Ready, SLI & Crossfire Ready

Quark-1200, Quark Series 1200 W Full Modular Power Supply with LED Indicator, 80Plus Platinum Certified, Single +12V Rail, Intel 4th Gen CPU Ready, SLI & Crossfire Ready

Rosewill Quark 1200 – Quark Series 1200 W Full Modular Power Supply with LED Indicator, 80Plus Platinum Certified, Single +12V Rail, Intel 4th Gen CPU Ready, SLI & Crossfire Ready

SKU: 17-182-354 Category:

Description


rosewill
rosewill

FEATURES

rosewill

80 Plus Platinum Certified delivers over 92% efficiency



rosewill

LED lights will indicate a malfunction on +3.3V, +5V, +12V and other rails



rosewill

Fully modular design provides cable management



rosewill

ATX 12V V2.3 ready, supports EPS 12V 2.92 and backward compatible with ATX 12V 2.01



rosewill

Active Power Factor Correction (PFC) with PF value of 0.99



rosewill

Crossfire and SLI support



rosewill

Silent 135 mm fan with auto-speed control



rosewill

100% High-Quality Japanese capacitors



rosewill

Over Current/Voltage/Temperature/Power Protection, Short Circuit Protection, and Under Voltage Protection



rosewill

UL, FCC, CE, Nemko Certified

rosewill



rosewill

Extra-long cables support full size gaming chassis



rosewill

5-Year Warranty



SPECIFICATIONS

Model: Quark 1200

AC INPUT 115 ~ 240V  12 – 6A   60 – 50Hz
DC OUTPUT
+3.3V +5V +12V -12V +5VSB
25A 22A 100A 0.3A 2.5A
120W 1200W 3.6W 12.5W
TOTAL POWER 1200W

CONNECTORS

rosewill
Motherboard
Cable
20+4-Pin
Connector x1
rosewill
+12V EPS
Cable
4+4-Pin
Connector x2
rosewill
PCIe Cable
6+2-Pin
Connector x8
rosewill
SATA Cable
15-Pin
Connector x15
rosewill
Peripheral
Cable
Molex 4-Pin
Connector x5
rosewill
FDD Cable
4-Pin
Connector x1

PACKAGE CONTENTS

  • Quark Power Supply Unit x1
  • Modular Cable Set x1
  • Cable Bag x1
  • User Manual x1
  • AC Power Cord x1
  • Cable Tie x3
  • Mounting Screws x4

Additional information

Dimensions 13.3 x 9.5 x 4.6 in
Model Number

Quark 1200

Customer Service

Customer Service and Technical Support

Toll Free: 1 (800) 575-9885
FAX: (626) 271-9504

Customer Service and Technical Support Hours: Monday – Friday, 8:00 AM – 5:00 PM (PST)

Support Email: techsupport@rosewill.com
Warranty and RMA Email: rma@rosewill.com

To register your product for warranty, please click on Warranty Registration.

Downloads

User Manuals

Quark_Series_650-1200_PSU_UM.pdf
