///RNX-AC1200UBv2 – USB 3.0 Dual Band Wireless AC1200 Wi-Fi Adapter

RNX-AC1200UBv2 – USB 3.0 Dual Band Wireless AC1200 Wi-Fi Adapter

Buy now
SKU: 33-166-132 Category:

Rosewill
Rosewill

Rosewill
Rosewill

  • IEEE 802.11 ac: Backward compatible with IEEE 802.11a / b / g / n
  • Dual Band for all devices: 2.4GHz + 5GHz to support all your devices
  • Ultimate Speed: Speed up to 300 + 867 Mbps (2.4GHz + 5.0GHz)
  • USB 3.0: Super speed USB 3.0, backward compatible with USB 2.0

Rosewill

The Next Generation of Wi-Fi

Provides the latest wireless technology 802.11ac, allowing the adapter to connect with a 2.4 GHz or 5.0 GHz network. Experience better video streaming and online gaming with the 5 GHz band and use the 2.4 GHz band for simple tasks such as sending e-mails or website browsing.

Rosewill

Rosewill

Ultimate Speed Up To 300 + 867Mbps

The 2.4 GHz band supports a maximum speed of up to 300 Mbps, for normal use such as web surfing. The 5 GHz band supports a maximum speed of up to 867 Mbps, providing a hassle free wireless network with improved performance for activity such as online gaming, HD video streaming, VoIP phone calling, and much more.

Rosewill

Ultra-Fast USB 3.0

Achieve amazing data transfer speeds of up to 4.8 Gbps with USB 3.0 – the highest USB connectivity standard. USB 3.0 technology transfers data up to 10 times faster than USB 2.0, and is also backward compatible with USB 2.0.

Rosewill

Advanced Wireless Security

Advanced WPA / WPA2 encryptions, created by the Wi-Fi Alliance, provide interoperability and security for WLAN, which effectively and efficiently protect users’ wireless environments.

Rosewill

Bundled USB Extension Cable

A 3-foot USB 3.0 extension cable comes bundled- making it easier to apply, remove and set in a more convenient location.

Easy Setup

Rosewill

Brand

Rosewill

Model

RNX-AC1200UBv2

Standards

IEEE 802.11ac, IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Wireless Data Rates

2.4 GHz Up to 300 Mbps
5.0 GHz Up to 867 Mbps

Security

Support 64 / 128 bit WEP, WPA-PSK / WPA2-PSK, 802.1x

Interface

USB 3.0

Frequency Band

2.4 GHz

Antenna

No

System Requirements

Windows 10 (32 / 64-bit), Windows 8 (32 / 64-bit), Windows 7 (32 / 64-bit), Windows XP (32 / 64-bit)

Features

Next Generation Standard 802.11AC, compatible with 11 a/b/g/n

Up to 300 Mbps at 2.4 GHz

Up to 867 Mbps at 5.0 GHz

Dual Band connections for lag-free HD video streaming and gaming

Wireless Mode: Ad-Hoc / Infrastructure mode

Support WPS button for easy connection

USB 3.0 Interface Supported

Windows 10 Compatibility

Portable dongle type design

Equipped with a USB 3.0 1.0m Extension Cable for flexible deployment

Dimensions

0.30" x 3.10" x 1.00"

Temperature

Operating Temperature: 0 ~ 40 degree Celsius (32 ~ 104 degree Fahrenheit)
Storage Temperature: -40 ~ 70 degree Celsius (-40 ~ 158 degree Fahrenheit)

Humidity

Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing

Package Contents

1 x AC1200 Wireless USB Adapter
1 x Resource CD
1 x Quick Installation Guide
1 x USB Extension Cable

Class

AC1200

Customer Service and Technical Support

Toll Free: 1 (800) 575-9885
FAX: (626) 271-9504

Customer Service and Technical Support Hours: Monday – Friday, 8:00 AM – 5:00 PM (PST)

Support Email: techsupport@rosewill.com
Warranty and RMA Email: rma@rosewill.com

To register your product for warranty, please click on Warranty Registration.

Drivers

33-166-132_RNX-AC1200UB2_Linux.2017Aug.v1.zip
33-166-132_RNX-AC1200UB2_MAC_OS_X..2017Aug.v1.zip
33-166-132_RNX-AC1200UB2_Windows.2017Aug.v1.zip

User Manuals

33-166-132_RNX-AC1200UBv2_A-QIG_OL.pdf
