///RNX-AD10D – High Power / Gain True 10 dBi Dual Band Network Directional Antenna – Most Powerful DualBand Antenna on Earth

RNX-AD10D – High Power / Gain True 10 dBi Dual Band Network Directional Antenna – Most Powerful DualBand Antenna on Earth

SKU: 33-998-208 Category:

Description

Rosewill RNX-AD10D 10dBi High Gain Dual Band Network Directional Antenna

Your Best Choice of Dual Band Antenna

Complaints about the poor signal of your Wi-Fi from a 802.11AC router? Why not try the Real High Gain Dual Band Network Antenna Stand of Rosewill. According to the research, the Wi-Fi range of 802.11AC is only half of 802.11n.

It means when you upgrade your wireless router to 802.11AC, the distance of your indoor Wi-Fi coverage is no longer the same as you were used to before. To help customers use the Wi-Fi conveniently, Rosewill launches a series of Real Dual Band Network Antenna products. Unlike the low cost and counterfeit dual band antennas, we test our network antennas rigorously to create ubiquitous indoor Wi-Fi environments for users.

Still feeling annoyed with your Wi-Fi range? Give the network antennas from Rosewill a try.

Applied Routers Included not Limited To:

  • ASUS: RT-AC68U, RT-N66U RT-AC66U
  • NETGEAR: R7000,
  • D-Link: DIR-655 DIR-665
  • TP-LINK: TL-WDR4300, TL-WDR3600, TL-WDR3500, TL-WR1043ND, TL-WR2543ND, TL-WDR4300
  • Buffalo: WZR-HP-G450H
  • Rosewill: RNX-AC750RT, RNX-AC1200RT, RNX-AC1750RT
  • And all wireless routers, wireless adapters and repeaters with detachable antennas

Features

rosewill

Real Dual Band 10dBi

Real dual band and 10dBi compared to existing antennas

Compatible with 802.11 ac/n/g/b/

Compatibility with 11ac routers to extend the short range of Wi-Fi.

Dual Band (2.4 / 5.0GHz)

Compatibility with 11ac routers to extend the short range of Wi-Fi

High Gain

Amplifying signal to provide longer coverage for your Wi-Fi network

Plug and Play

PNP makes your setup easily


Why You Should Choose the 11AC Standard?

rosewill
rosewill

Wrong Method

Interference between closed antennas makes signal decay


rosewill

Replaced with Real Dual Band Antenna

Should keep 3.1 – 4-inch (8 – 10cm) between your antennas


rosewill

Equipped with Directional Antenna

Use directional antennas to signal where your are.


rosewill

Equipped with ULA100 Cable Stands

Antenna stands are the best way for wireless signal coverage.


More Suggestions
Modle# RNX-AD7D RNX-AD5 RNX-AD7 RNX-AD10D RNX-AS14001
Photo comparison comparison comparison comparison comparison
Features High Gain 7dBi Real 5dBi Wider 7dBi High Gain 10dBi 3dBi retained by ULA100
Wireless Standard 802.11 ac/n/g/b/a 802.11 ac/n/g/b/a 802.11 ac/n/g/b/a 802.11 ac/n/g/b/a 802.11 ac/n/g/b/a
dBi 5/7 3/5 5/7 7.5/10 ULA100 Cable

2 – 3dBi Reserved

Intervention Avoidance
Frequency (MHz) 240 – 2500
5100 – 5870
240 – 2500
5100 – 5870
240 – 2500
5100 – 5870
240 – 2500
5100 – 5870
Directional rosewill rosewill
High Gain rosewill rosewill
Plug and Play rosewill rosewill rosewill rosewill rosewill
Applied to Dual Band Devices rosewill rosewill rosewill rosewill rosewill
RP – SMA Male Connector rosewill rosewill rosewill rosewill rosewill
Specifications
Frequency 2400 – 2500MHz 5150 – 5875MHz
Peak Gain 7.5dBi 10dBi
VSWR 2.0: 1 Max. 2.0: 1 Max.
Polarization Linear, vertical Linear, vertical
HPBW / Horizontal 70 Degrees 60 Degrees
HPBW / Vertical 60 Degrees 30 Degrees
Impedance 50Ω
Connector RP SMA PLUG
Environmental & Mechanical Characteristics
Temperature 14 – 131°F (-10 – 55°C)
Humidity 95% @ 77°F (25°C)

rosewill
rosewill
rosewill

Additional information

Weight 0.15 lbs
Dimensions 6 x 3.1 x 1.3 in
Model Number

RNX-AD10D
